01 / Authentication

One operator token, two portal rails

All operator endpoints live under /api/v1/switch and require your operator bearer token in the Authorization header. Self-service portals are separate, magic-link-authenticated rails.

Operator API: Authorization: Bearer <operator_api_key> under /api/v1/switch.
Customer portal: /api/v1/sub-portal - the auth/* endpoints are public (magic-link request/verify); all others need the portal session token minted at verify.
Supplier portal: /api/v1/vendor-portal - same magic-link model as the customer portal.
Every response is wrapped as { success, data } except raw documents (invoice HTML/XML, portal CSV). Resources are scoped to your operator - another operator's resource returns 404.

bash

curl "https://packetexchange.io/api/v1/switch/entity-counts" \
  -H "Authorization: Bearer <operator_api_key>"

# → { "success": true, "data": { "customers": 0, ... } }

02 / Getting started

Zero to a previewable route

Create a supplier trunk

POST /suppliers with { label, sipHost, transport }. (Or promote a purchased marketplace route via /suppliers/promote.)

Add a cost deck

POST /suppliers/:id/rates/bulk with your termination rates - billed longest-prefix on live traffic.

Create a route group

POST /route-plans, then PUT /route-plans/:id/entries. Priorities give failover; weights load-balance.

Create a customer

POST /customers. The 201 returns the customer’s first apiKey + sipPassword (shown once) - hand these off so they can send you traffic.

Assign routing + preview

POST /customers/:id/routing to bind a plan, then GET /routing/preview?to=... for the resolved dialplan verdict + ordered failover chain (no side effects).

From there: add a retail SELL deck (POST /sell-rates/bulk), and once traffic flows, generate invoices, record payments, and run settlement. Give both sides self-serve visibility by setting portalEmail and calling the portal-invite endpoints.

bash

curl "https://packetexchange.io/api/v1/switch/routing/preview?to=14155551234&subAccountId=<customerId>" \
  -H "Authorization: Bearer <operator_api_key>"

# → resolved dialplan verdict + ordered
# candidates[] failover chain (supplier,
# matchedPrefix, price) - no side effects

03 / Customers, Suppliers & Provisioning

Bring suppliers in, connect customers out

Sell-side customers (sub-accounts with their own API key + SIP creds) and buy-side supplier vendor trunks, plus inbound IP ACLs and magic-link portal invites. All under /api/v1/switch, operator bearer auth.

Customers

GET/switch/customers

List sell-side customers

POST/switch/customers

Create customer (returns apiKey + sipPassword once)

GET/switch/customers/:id

Get customer + IP ACLs

PATCH/switch/customers/:id

Update fields / status

POST/switch/customers/:id/portal-invite

Email a magic-link portal login

POST/application/sub-accounts/:id/credit

Move funds operator → customer. Body { amount } (positive)

POST/application/sub-accounts/:id/debit

Charge a customer balance, e.g. a plan or bundle. Body { amount (positive), reason }

Suppliers

GET/switch/suppliers

List supplier vendor trunks

POST/switch/suppliers

Create external supplier trunk

POST/switch/suppliers/promote

Promote a purchased marketplace route

GET/switch/suppliers/:id

Get trunk + IP ACLs

PATCH/switch/suppliers/:id

Update trunk

DEL/switch/suppliers/:id

Delete trunk (cascades plan entries)

POST/switch/suppliers/:id/portal-invite

Email a magic-link portal login

IP ACLs

GET/switch/acls

List ACLs for a customer/trunk

POST/switch/acls

Add an inbound IP/CIDR ACL

DEL/switch/acls/:id

Delete an ACL

Overview

GET/switch/entity-counts

Customer + supplier counts (native vs external)

04 / Routing

Dialplans, route groups, LCR & failover

Route plans (ordered suppliers with priority/weight and SIP-code failover), dialplans (match → manipulate → route/block rules), per-customer assignment, and a read-only preview that resolves the full failover chain with no side effects.

Route plans (route groups)

GET/switch/route-plans

List route plans

POST/switch/route-plans

Create route plan (maxAttempts, failoverSipCodes)

GET/switch/route-plans/:id

Get plan + entries

PATCH/switch/route-plans/:id

Update plan

DEL/switch/route-plans/:id

Delete plan (entries cascade)

PUT/switch/route-plans/:id/entries

Replace all entries (priority/weight)

Dialplans

GET/switch/dialplans

List dialplans

POST/switch/dialplans

Create dialplan

GET/switch/dialplans/:id

Get dialplan + rules

PATCH/switch/dialplans/:id

Update dialplan

DEL/switch/dialplans/:id

Delete dialplan (rules cascade)

PUT/switch/dialplans/:id/rules

Replace all rules (match/manipulate/route)

Per-customer routing

GET/switch/customers/:id/routing

Get assigned dialplan / plan / strategy

POST/switch/customers/:id/routing

Assign dialplan / plan / strategyOverride

Preview

GET/switch/routing/preview

Resolve dialplan + ordered failover chain (no side effects)

05 / Rating

Retail SELL decks & per-trunk COST decks

A-Z rate decks billed longest-prefix on live traffic. Prefixes are cleaned to digits (max 24 chars). Single upserts, bulk imports (up to 50,000 rows), deletes, and clears.

Sell rates (retail SELL deck)

GET/switch/sell-rates

List sell rates (search/limit/offset)

POST/switch/sell-rates

Upsert a sell rate (fires webhook)

POST/switch/sell-rates/bulk

Bulk upsert sell deck (fires webhook)

DEL/switch/sell-rates/:id

Delete a sell rate

POST/switch/sell-rates/clear

Clear deck (all or given prefixes)

Supplier cost rates (per-trunk)

GET/switch/suppliers/:id/rates

List cost rates for a trunk

POST/switch/suppliers/:id/rates

Upsert a supplier cost rate

POST/switch/suppliers/:id/rates/bulk

Bulk upsert cost deck

DEL/switch/suppliers/:id/rates/:rateId

Delete a cost rate (archived, recoverable)

POST/switch/suppliers/:id/rates/clear

Clear the trunk cost deck (archives it)

GET/switch/suppliers/:id/rates/archived

List archived deck generations

POST/switch/suppliers/:id/rates/restore

Restore an archived cost deck

06 / Billing (AR invoices)

Invoices from settled CDR usage

Generate AR invoices over a period, record payments, void, email, render HTML/XML, issue credit notes, and pull AR aging. Invoice print (HTML) and xml return raw documents (not envelope-wrapped).

Invoices

GET/switch/invoices

List invoices (customer/status filters)

POST/switch/invoices

Generate invoice from settled CDRs

GET/switch/invoices/:id

Get invoice + lines + payments

POST/switch/invoices/:id/payments

Record a payment

POST/switch/invoices/:id/void

Void invoice

POST/switch/invoices/:id/send

Email invoice to portal email

GET/switch/invoices/:id/print

Render invoice HTML (raw)

GET/switch/invoices/:id/xml

Export invoice XML (raw)

Credit notes, aging & settings

GET/switch/credit-notes

List credit notes

POST/switch/credit-notes

Issue a credit note

GET/switch/ar-aging

AR aging buckets

POST/switch/customers/:id/billing-settings

Set billing cycle + payment terms

07 / Settlement (AP, counterparties, netting)

Payables, counterparties & netting

AP payables generated from supplier cost, bilateral counterparties, and netting runs that offset AR against AP over a period.

Payables

GET/switch/payables

List payables (trunk/status filters)

POST/switch/payables

Generate payable from CDR cost

GET/switch/payables/:id

Get payable + lines + payments

POST/switch/payables/:id/payments

Record supplier payment

POST/switch/payables/:id/void

Void payable

GET/switch/ap-aging

AP aging buckets

Counterparties & netting

GET/switch/counterparties

List counterparties

POST/switch/counterparties

Create counterparty

PATCH/switch/counterparties/:id

Update counterparty

DEL/switch/counterparties/:id

Delete counterparty

POST/switch/counterparties/:id/netting

Run netting (AR minus AP)

GET/switch/netting-runs

List netting runs

08 / Reporting & Fraud

Analytics & fraud controls

A shared metric shape (revenue, cost, margin, ASR, ACD, minutes, PDD) across overview, daily time-series, and top-100 breakdowns by customer / supplier / destination - plus per-operator fraud thresholds, high-risk prefixes, and an event feed.

Analytics

GET/switch/analytics/overview

Single metric object for a range

GET/switch/analytics/timeseries

Daily time-series metrics

GET/switch/analytics/breakdown

Top-100 by customer/supplier/destination

Fraud

GET/switch/fraud/settings

Get fraud config (scores, prefixes)

POST/switch/fraud/settings

Update fraud thresholds + prefixes

GET/switch/fraud/events

Event feed (newest first)

GET/switch/fraud/summary

30-day total / blocked / flagged

09 / Self-service Portals

Magic-link portals for both sides

Customers (/api/v1/sub-portal) and suppliers (/api/v1/vendor-portal) get self-serve visibility into CDRs, invoices/payables, rate cards, and key rotation. The auth/* endpoints are public; everything else uses the portal session token minted at verify.

Customer portal (/sub-portal)

POST/sub-portal/auth/request-link

Request magic link (public)

POST/sub-portal/auth/verify

Verify → mint session token (public)

GET/sub-portal/me

Identity, balance, usage, branding

GET/sub-portal/cdrs

Recent CDRs

GET/sub-portal/cdrs-filtered

CDRs filtered by date/kind

GET/sub-portal/cdrs.csv

CDR CSV download (raw)

GET/sub-portal/invoices

Their invoices

GET/sub-portal/rate-card

Markup + effective rates

GET/sub-portal/keys

API key metadata

POST/sub-portal/keys/rotate

Rotate key (returned once)

POST/sub-portal/topup-request

Request a top-up (notify only)

Supplier portal (/vendor-portal)

POST/vendor-portal/auth/request-link

Request magic link (public)

POST/vendor-portal/auth/verify

Verify → mint session token (public)

GET/vendor-portal/me

Identity, earnings, outstanding owed

GET/vendor-portal/cdrs

Their traffic CDRs (sellerCredit)

GET/vendor-portal/cdrs.csv

Traffic CSV download (raw)

GET/vendor-portal/payables

Their payables

GET/vendor-portal/payments

Payments received

10 / Webhooks

Events emitted on key writes

Certain Switch writes fire webhooks you can subscribe to:

sell_rate.changedinvoice.createdinvoice.paymentinvoice.sentcredit_note.issuedsub_account.topup_requested

sell_rate.changed carries a kind of upsert or bulk_import. Register webhook endpoints via the core account API.
