Documentation

From API key to first call

Quick starts for SMS, phone verification and price-a-number, the full REST reference, the MCP server for agents, the Switch API, and how to connect your switch over SIP or SMPP.
Quickstarts
12
References
3
MCP tools
33
Ways to connect
SIP, SMPP, REST, MCP

How you connect

Four protocols, pick what your stack speaks

SIP

Voice trunking

Point your switch at the addresses below and authenticate by IP (no registration needed) or per-route username and password, issued instantly on the dashboard Interconnections page.

SMPP

SMS binds

Buy an SMS route and your bind credentials and host arrive on the Interconnections page, with a one-click bind test. Throughput follows the capacity your route contracts for.

REST

HTTP API

Every platform function over HTTPS, with scoped API keys, signed webhooks and test keys.

MCP

For agents

33 tools your agent calls by name, on one hosted endpoint.

Send SIP to 5.9.65.215:5060, failing over to 94.130.218.11:5060, over UDP or TCP. Codecs are G.711 and G.729. Credentials and your IP allow-list are issued per purchase, and an IP change reaches the edge in about 30 seconds. If your switch cannot register with a username and password, use IP authentication: it needs no registration at all. The full SIP profile is in the REST API reference.

Which of our addresses to allow

When we send calls to a switch, it has to allow the address the calls come from. Which one depends on what you set up, not on who owns the switch: if the switch belongs to a carrier you buy from, ask them to allow it.

A route you list on the marketplaceYour own sending address, or 144.76.120.84 and 138.201.81.168New sellers are normally given their own sending address when they list; then all our calls to their listings come from that one address. Otherwise both shared addresses, for signalling and media (UDP 16384 to 32768). The Endpoint step of your listing shows exactly which applies to you.
A supplier on your PacketExchange Switch144.76.120.84 and 138.201.81.168Unless your account is cleared to send from your dedicated address. The Dedicated IP card on your Switch says which applies to you.
Your dedicated addressReceives callsWhere your customers send calls to you. It never sends calls to your marketplace listings, so do not give it to a carrier for those.
Where you send calls to us5.9.65.215, then 94.130.218.11Port 5060 over UDP or TCP.
